5083 ultra-flat aluminum plate is with O temper. It hardness and strength is higher than 5052 aluminum plate. Its thickness can be up to 600 mm. 5083 aluminum plate has high flatness, high thickness tolerance precision, no deformation, good cutting performance, good polishing performance, and excellent corrosion resistance. It also has good anodizing and welding performance.

As an experienced aluminium sheet supplier, LY Aluminum has both two kinds of aluminum sheets. We also have other aluminum alloys such as 3003 and 6061 aluminum sheet. Welcome to leave message below to get the latest price.

Chemical Composition of Aluminium Alloy 5083

Table 1. Chemical composition for aluminium alloy 5083

Element	% Present
Si	0.4
Fe	0.4
Cu	0.1
Mn	0.4-1.0
Mg	4.0-4.9
Zn	0.25
Ti	0.15
Cr	0.05-0.25
Al	Balance



Properties of Aluminium Alloy 5083

Mechanical Properties of Aluminium Alloy 5083

Table 2 (a). Mechanical properties for aluminium alloy 5083 Soft O/H111

BS EN 485-2:2008 Sheet 0.2 - 6.3mm Thick
Property	Value
Proof Stress	125 Min MPa
Tensile Strength	275 - 350 MPa
Hardness Brinell	75 HB

*Properties above are for material in the Soft O/H111 condition

---

Table 2 (b). Mechanical properties for aluminium alloy 5083 Soft O/H111

BS EN 485-2:2008 Plate 6.3mm to 80mm
Property	Value
Proof Stress	115 Min MPa
Tensile Strength	270 - 345 MPa
Hardness Brinell	75 HB

*Properties above are for material in the Soft O/H111 condition

---

Table 2 (c). Mechanical properties for aluminium alloy 5083 Soft O/H111

BS EN 485-2:2008 Plate 80mm to 120mm
Property	Value
Proof Stress	110 Min MPa
Tensile Strength	260 Min MPa
Hardness Brinell	70 HB
Elongation A	12 Min %

*Properties above are for material in the Soft O/H111 condition

---

Table 2 (d). Mechanical properties for aluminium alloy 5083 H32

BS EN 485-2:2008 Sheet 0.2mm to 6.00mm
Property	Value
Proof Stress	215 Min MPa
Tensile Strength	305 - 380 MPa
Hardness Brinell	89 HB

*Properties above are for material in the H32 condition

---

Physical Properties of Aluminium Alloy 5083

Table 3. Physical properties for aluminium alloy 5083

Property	Value
Density	2650 kg/m3
Melting Point	570°C
Modulus of Elasticity	72 GPa
Electrical Resistivity	0.58 x 10-6 Ω.m
Thermal Conductivity	121 W/m.K
Thermal Expansion	25 x 10-6/K



Alloy Designations

Aluminium 5083 also corresponds to the following standard designations and specifications:

• Al Mg4.5Mn0.7
• AlMg4.5Mn
• GM41
• A95083

Fabrication of Aluminium Alloy 5083

Welding

When welding Aluminium 5083 to itself or another alloy from the same sub-group, the recommended filler metal is 5183. Other suitable fillers are 5356 and 5556.

Fabrication Response

Table 4. Fabrication response for aluminium alloy 5083

Process	Rating
Workability – Cold	Average
Machinability	Poor
Weldability – Gas	Average
Weldability – Arc	Excellent
Weldability – Resistance	Excellent
Brazability	Poor
Solderability	Poor



Temper

The most common tempers for Aluminium 5083 are:

• 0 – Annealed wrought alloy
• H111 – Some work hardening imparted by shaping processes but less than required for a H11 temper.
• H32 – Work hardened and stabilised with a quarter hard temper.

Applications of Aluminium Alloy 5083

Aluminium 5083 is used in:

• Shipbuilding
• Rail cars
• Vehicle bodies
• Tip truck bodies
• Mine skips and cages
• Pressure vessels

    If you need product information or price, please fill in your contact information in the form, we will usually contact you within 12 hours. You could also email me info@lyapm.com to get prompt reply.



     1. Stock view

Products Description

Aluminum	Aluminum Grade
STANDARD	ASTM B209,JIS H4000-2006,GB/T 3190-2008,GB/T 3880-2006,etc.
1000 Series	1050 1060 1070 1100
2000 Series	2024(2A12), LY12, LY11, 2A11, 2A14(LD10), 2017, 2A17
3000 Series	3A21, 3003, 3103, 3004, 3005, 3105
4000 Series	4A03, 4A11, 4A13, 4A17, 4004, 4032, 4043, 4043A, 4047, 4047A
5000 Series	5052, 5083, 5754, 5005, 5086,5182
6000 Series	6063, 6061, 6060, 6351, 6070, 6181, 6082, 6A02
7000 Series	7075,7050,7A04,7472,7475
Thickness(mm)	aluminum plate 0.2mm-300mm
Width(mm)	100-2800mm
Length(mm)	2000mm,2440mm,6000mm,or as required.
Surface	Wire drawing,oxidation,PS,Mirror surface,Embossing etc
Temper	H111 H112 H116/H321 H12/H22/H32 H14/H24/H34/H16/H26/H36 H18/H28/H38 H114/H194, etc
Type	coil/sheet/strips/plate

2. Processing and Technology for heating processing

Cutting processing      Quenching              Tempering                  Annealing



3. Quality testing

1.      Inspection Institution

Shanghai Fuda Testing Technology Group Co., LTD. Nanjing Branch

Focus on analysis, testing, testing, r & D four service areas. Analysis fields include component analysis, formula analysis, failure analysis, structure analysis, methodology development and validation, raw material quality control/evaluation, consistency evaluation, feature analysis and other directions; The testing field involves physical and chemical properties testing, toxic and harmful substances testing, flame retardant performance testing, reliability testing and other directions; The testing field involves energy spectrum, electron microscope, spectrum, chromatography, mass spectrometry and other directions; The r&d field involves formula development, formula upgrading, formula customisation, cooperative research and development and other directions.

Beijing Zhongke Chemical Technology Research Institute

It is a chemical technology research institution based on scientific research and testing. They adhere to paying equal attention to basic research and applied research, and combining applied research and technology transformation, developing into a comprehensive research institute characterised by "task-oriented disciplines". Approved by the relevant national departments, the company has become a third-party analysis and testing technology service unit, and has obtained CMA qualification certification. It has carried out research and development and design, analysis and testing, test and verification, generic processing, information and intellectual property services, providing public services for innovation of technology-based enterprises. Supported by the government innovation Fund, the institute has been awarded as a national high-tech enterprise.



2.Inspection Machining



According to the requirements of the state of steel materials, the use of binding, bare, frame, pallet.

Packing standard: according to the following national standard requirements (the parts beyond the requirements will be specified separately)

GB／T191 packaging-pictorial marking for handling of goods

GB／T4857 (all parts) basic test for transport packages

GB／T4879 rustproof packaging

GB／T5048 damp-proof packing

GB／T7350water-proof packing

GB／T8166 Package cushioning design

GB/T4892-1996  Hard straight square transport packaging size series

GB/T13201-91 Cylinder transport package size series

 GB/T16471-1996Design and make the size limit of transport package

5. Logistic

1. Company profile

Luoyue Precision Metal established in 2018, is a leading Stockists and global distributor for Metal Raw Materials like Steel/Aluminum/ Stainless steel/Copper/ Nickel Rods, Bars, Plates, Sheets,Pipes, fittings, fasteners, Inconel alloys, Wire and Wire-Mesh to customers from aerospace, automotive, electronics, precision manufacturing, ordnance, marine, shipbuilding, oil & gas, power plant and construction.

The company has a high-precision, high-efficiency modern processing site, CNC machine tools and complete testing and inspection technology, and introduces international advanced technologies.

           2. Certificates. (Business certificate/ISO9001/Trading certificate/SGS/FormE)

                  .

          3. Our customers

                 Customer visits

           4. Past Inquiry

                  .

   1.Customer Rating



FAQ
1. Q: Are you a manufacturer?
 A:No, we are not manufacturers. We have our own warehouse and our own company. I believe we will be the most suitable supplier for you.
2. Could we visit your factory?
 A: Sure, we welcome you to visit the factory , check our production lines and know more about our strength and quality.
3. Q: Do you have quality control system?
 A: Yes, we have ISO, BV, SGS certifications and our own quality control laboratory.
4. Q: Can you arrange the shipment for us?
 A: Yes, we have designated sea freight and railway freight forwarders with decades of experiences and we get the best  price with earliest vessel and professional service.
5. Q: How long is the delivery time?
 A: Generally it is 7 days if we have the exact goods in our stock. If not, it will take around 15-20 days to get goods ready for delivery.
6. Q: Can I get some samples?
 A: We are glad to provide free samples to you, but we do not offer the freight.
7. Q: What is your after-sale service?
 A: We provide after-sale service and offer 100% guarantee on our products.
8. Q: What is your MOQ?
 A: 2 Tons
