Chemical Composition

	Elements
	Cu(1)	Pb	Zn	Fe
(1) Cu + Sum of Named Elements 99.7% min.
Min (%)	59.0
Max (%)	63.0	0.09	Rem	0.07

Elements
Cu(1)	Pb	Zn	Fe
(1) Cu + Sum of Named Elements 99.7% min.
Min (%)	59.0
Max (%)	63.0	0.09	Rem	0.07

Mechanical Properties *

Form	Temper	Temper Code	Tensile Strength (ksi)	YS-0.5% Ext (ksi)	Elongation (%)	Rockwell B scale	Rockwell F scale	Rockwell 30T scale	Shear Strength (ksi)	Torsion Modulus (ksi)	Ultimate Tensile Strength in Shear (ksi)	Section Size (in)	Cold Work (%)
* Measured at room temperature, 68°F (20°C).
Flat Products	1/2 Hard	H02	70 Typ	50 Typ	10 Typ	75 Typ		67 Typ	44 Typ			0.04
	1/8 Hard	H00	60 Typ	35 Typ	30 Typ	55 Typ		54 Typ	42 Typ			0.04
	As Hot Rolled	M20	54 Typ	21 Typ	45 Typ		85 Typ	49 Typ	40 Typ			0.04
	Soft Anneal	O60	54 Typ	21 Typ	45 Typ		80 Typ	46 Typ	40 Typ			0.04
Flat Products & Rod	Annealed	O61	54 Typ	21 Typ	45 Typ						40 Typ	0.04
	Annealed	O61	54 Typ	21 Typ	50 Typ						40 Typ	1
Rod	1/4 Hard	H01	72 Typ	50 Typ	25 Typ	78 Typ				5.7 Typ	45 Typ	1
	As Hot Extruded	M30	52 Typ	20 Typ	52 Typ		78 Typ		39 Typ			1
	Soft Anneal	O60	54 Typ	21 Typ	50 Typ		80 Typ		40 Typ			1
Tube	Hard	H04	74 Typ	55 Typ	10 Typ	80 Typ							30
	Light Anneal	O50	56 Typ	23 Typ	50 Typ		82 Typ	47 Typ

Physical Properties

Melting Point - Liquidus°F	1660
Melting Point - Solidus°F	1650
Densitylb/cu in. at 68°F	0.303
Specific Gravity	8.39
Electrical Conductivity% IACS at 68°F	28
Thermal ConductivityBtu/ sq ft/ ft hr/ °F at 68°F	71
Coefficient of Thermal Expansion 68-57210 to -6 power per °F (68 – 572°F)	11.6
Specific Heat CapacityBtu/ lb /°F at 68°F	0.09
Modulus of Elasticity in Tensionksi	15000
Modulus of Rigidityksi	5600

Fabrication Properties

Technique	Suitability
Soldering	Excellent
Brazing	Excellent
Oxyacetylene Welding	Good
Gas Shielded Arc Welding	Fair
Coated Metal Arc Welding	Not Recommended
Spot Weld	Good
Seam Weld	Not Recommended
Butt Weld	Good
Capacity for Being Cold Worked	Fair
Capacity for Being Hot Formed	Excellent
Forgeability Rating	90
Machinability Rating	40

Thermal Properties

Treatment	Minimum*	Maximum*
* Temperature is measured in Fahrenheit.
Annealing	800	1100
Hot Working Temperature	1150	1450

Typical uses

Product Category	Product	Reason Category	Reason
Architecture	Architectural Panels	Appearance	Appearance
	Architectural Panels	Forming Characteristics	Formability
	Decoration	Appearance	Appearance
	Decoration	Corrosion Resistance	Corrosion Resistance
	Decoration	Mechanical Properties	Moderate Strength
	Door Frames	Appearance	Color
	Door Frames	Mechanical Properties	Moderate Strength
	Hardware	Appearance	Appearance
	Hardware	Corrosion Resistance	Corrosion Resistance
	Hardware	Forming Characteristics	Formability
	Hardware	Machining Characteristics	Machinability
	Hardware	Mechanical Properties	High Strength
	Large Architectural Trim	Appearance	Appearance
	Large Architectural Trim	Forming Characteristics	Formability
	Large Sheets	Appearance	Appearance
	Large Sheets	Forming Characteristics	Formability
	Large Sheets	Mechanical Properties	Moderate Strength
	Sheet	Appearance	Color
	Sheet	Corrosion Resistance	Corrosion Resistance
	Sheet	Mechanical Properties	High Strength
	Structural, Heavy Plate	Corrosion Resistance	Corrosion Resistance
	Structural, Heavy Plate	Mechanical Properties	High Strength
Builders Hardware	Decorative Hardware	Appearance	Appearance
	Decorative Hardware	Corrosion Resistance	Corrosion Resistance
	Decorative Hardware	Forming Characteristics	Formability
	Decorative Hardware	Machining Characteristics	Machinability
	Decorative Hardware	Mechanical Properties	High Strength
Fasteners	Bolts	Corrosion Resistance	Corrosion Resistance
	Bolts	Forming Characteristics	Formability
	Bolts	Machining Characteristics	Machinability
	Bolts	Mechanical Properties	High Strength
Industrial	Brazing Rod	Brazing Characteristics	Brazability
	Condenser Plates	Corrosion Resistance	Corrosion Resistance
	Condenser Plates	Corrosion Resistance	Corrosion Resistance to Fresh Water
	Condenser Plates	Corrosion Resistance	Corrosion Resistance to Salt Water
	Condenser Plates	Forming Characteristics	Formability
	Condenser Plates	Mechanical Properties	Moderate Strength
	Condenser Tube	Conductivity (Thermal)	Thermal Conductivity
	Condenser Tube	Corrosion Resistance	Corrosion Resistance
	Evaporator Tubes	Conductivity (Thermal)	Thermal Conductivity
	Evaporator Tubes	Corrosion Resistance	Corrosion Resistance
	Evaporator Tubes	Forming Characteristics	Formability
	Evaporator Tubes	Mechanical Properties	Moderate Strength
	Heat Exchanger Tube	Conductivity (Thermal)	Thermal Conductivity
	Heat Exchanger Tube	Corrosion Resistance	Corrosion Resistance
	Heat Exchanger Tube	Mechanical Properties	Moderate to High Strength
	Hot Forgings	Corrosion Resistance	Corrosion Resistance
	Hot Forgings	Forming Characteristics	Formability
	Hot Forgings	Mechanical Properties	Moderate Strength
	Large Nuts and Bolts	Corrosion Resistance	Corrosion Resistance
	Large Nuts and Bolts	Forging Characteristics	Hot Forgability
	Large Nuts and Bolts	Mechanical Properties	Moderate Strength
	Valve Stems	Corrosion Resistance	Corrosion Resistance
	Valve Stems	Forming Characteristics	Formability
	Valve Stems	Machining Characteristics	Machinability
	Valve Stems	Mechanical Properties	High Strength

Applicable Specifications

Form	Specific Sub-Form	Application	System	Standard	Description
Bar			ASTM	B36/B36M	BRASS PLATE, SHEET, STRIP AND ROLLED BAR
Plate			ASTM	B36/B36M	BRASS PLATE, SHEET, STRIP AND ROLLED BAR
Seamless Condenser Tube & Ferrule Stock		Condenser Tube	ASME	SB111	COPPER AND COPPER ALLOY SEAMLESS CONDENSER TUBES & FERRULE STOCK
		Condenser Tube	ASTM	B111/B111M	COPPER AND COPPER ALLOY SEAMLESS CONDENSER TUBES AND FERRULE STOCK
Seamless Tube			ASME	SB135	SEAMLESS BRASS TUBE
Sheet			ASTM	B36/B36M	BRASS PLATE, SHEET, STRIP AND ROLLED BAR
Strip			ASTM	B36/B36M	BRASS PLATE, SHEET, STRIP AND ROLLED BAR
Tube	Seamless (Metric)		ASTM	B135/B135M	Seamless Brass Tube
			ASTM	B135	Tube, Seamless
			FEDERAL	WW-T-791	TUBING: BRASS, SEAMLESS

If you need product information or price, please fill in your contact information in the form, we will usually contact you within 12 hours. You could also email me info@lyapm.com to get prompt reply.

1. Stock view



2. Processing and Technology for heating processing

Cutting processing      Quenching              Tempering                  Annealing



3. Quality testing

1.      Inspection Institution

Shanghai Fuda Testing Technology Group Co., LTD. Nanjing Branch

Focus on analysis, testing, testing, r & D four service areas. Analysis fields include component analysis, formula analysis, failure analysis, structure analysis, methodology development and validation, raw material quality control/evaluation, consistency evaluation, feature analysis and other directions; The testing field involves physical and chemical properties testing, toxic and harmful substances testing, flame retardant performance testing, reliability testing and other directions; The testing field involves energy spectrum, electron microscope, spectrum, chromatography, mass spectrometry and other directions; The r&d field involves formula development, formula upgrading, formula customisation, cooperative research and development and other directions.

Beijing Zhongke Chemical Technology Research Institute

It is a chemical technology research institution based on scientific research and testing. They adhere to paying equal attention to basic research and applied research, and combining applied research and technology transformation, developing into a comprehensive research institute characterised by "task-oriented disciplines". Approved by the relevant national departments, the company has become a third-party analysis and testing technology service unit, and has obtained CMA qualification certification. It has carried out research and development and design, analysis and testing, test and verification, generic processing, information and intellectual property services, providing public services for innovation of technology-based enterprises. Supported by the government innovation Fund, the institute has been awarded as a national high-tech enterprise.



2.Inspection Machining



   Metal composition testing machine                      Computerised Materials Torsion Testing Machine                Metal bar composite rod bending tensile strength testing machine

       3. Material test certificate

     4. Packaging

    In the steel export activities, we also need to pack the steel to prevent the steel from being scattered in the transportation process. In the hoisting process, it is necessary to lift the steel. So steel is very necessary in the export process. Below is the picture of packaging：

According to the requirements of the state of steel materials, the use of binding, bare, frame, pallet.

Packing standard: according to the following national standard requirements (the parts beyond the requirements will be specified separately)

GB／T191 packaging-pictorial marking for handling of goods

GB／T4857 (all parts) basic test for transport packages

GB／T4879 rustproof packaging

GB／T5048 damp-proof packing

GB／T7350water-proof packing

GB／T8166 Package cushioning design

GB/T4892-1996  Hard straight square transport packaging size series

GB/T13201-91 Cylinder transport package size series

 GB/T16471-1996Design and make the size limit of transport package

5. Logistic



1. Company profile

Luoyue Precision Metal established in 2018, is a leading Stockists and global distributor for Metal Raw Materials like Steel/Aluminum/ Stainless steel/Copper/ Nickel Rods, Bars, Plates, Sheets,Pipes, fittings, fasteners, Inconel alloys, Wire and Wire-Mesh to customers from aerospace, automotive, electronics, precision manufacturing, ordnance, marine, shipbuilding, oil & gas, power plant and construction.

The company has a high-precision, high-efficiency modern processing site, CNC machine tools and complete testing and inspection technology, and introduces international advanced technologies.

           2. Certificates. (Business certificate/ISO9001/Trading certificate/SGS/FormE)

                  .

          3. Our customers

                 Customer visits

           4. Past Inquiry

                  .

   1.Customer Rating



FAQ
1. Q: Are you a manufacturer?
 A:No, we are not manufacturers. We have our own warehouse and our own company. I believe we will be the most suitable supplier for you.
2. Could we visit your factory?
 A: Sure, we welcome you to visit the factory , check our production lines and know more about our strength and quality.
3. Q: Do you have quality control system?
 A: Yes, we have ISO, BV, SGS certifications and our own quality control laboratory.
4. Q: Can you arrange the shipment for us?
 A: Yes, we have designated sea freight and railway freight forwarders with decades of experiences and we get the best  price with earliest vessel and professional service.
5. Q: How long is the delivery time?
 A: Generally it is 7 days if we have the exact goods in our stock. If not, it will take around 15-20 days to get goods ready for delivery.
6. Q: Can I get some samples?
 A: We are glad to provide free samples to you, but we do not offer the freight.
7. Q: What is your after-sale service?
 A: We provide after-sale service and offer 100% guarantee on our products.
8. Q: What is your MOQ?
 A: 2 Tons
