Chemical Composition

	Elements
	Cu(1)	Pb	Zn	Fe
(1) Cu + Sum of Named Elements 99.7% min.
Min (%)	67.0
Max (%)	70.0	0.07	Rem	0.05

Mechanical Properties *

Form	Temper	Temper Code	Tensile Strength (ksi)	YS-0.5% Ext (ksi)	Elongation (%)	Rockwell B scale	Rockwell F scale	Rockwell 30T scale	Shear Strength (ksi)	Fatigue Strength** (ksi)	Section Size (in)	Cold Work (%)
* Measured at room temperature, 68°F (20°C).** Fatigue Strength: 100 x 106 cycles, unless indicated as [N] x 106.
Flat Products	1/2 Hard	H02	62 Typ	52 Typ	25 Typ	70 Typ		65 Typ	40 Typ	18 Typ	0.04
	1/4 Hard	H01	54 Typ	40 Typ	43 Typ	55 Typ		54 Typ	36 Typ		0.04
	Extra Hard	H06	86 Typ	65 Typ	5 Typ	88 Typ		76 Typ	46 Typ		0.04
	Extra Spring	H10	99 Typ	65 Typ	3 Typ	93 Typ		78 Typ			0.04
	Hard	H04	76 Typ	63 Typ	8 Typ	82 Typ		73 Typ	44 Typ	21 Typ	0.04
	Nominal Grain Size 0.015 mm	OS015	53 Typ	22 Typ	54 Typ		78 Typ	43 Typ	35 Typ		0.04
	Nominal Grain Size 0.025 mm	OS025	51 Typ	19 Typ	55 Typ		72 Typ	36 Typ			0.04
	Nominal Grain Size 0.035 mm	OS035	49 Typ	17 Typ	57 Typ		68 Typ	31 Typ	34 Typ	14 Typ	0.04
	Nominal Grain Size 0.050 mm	OS050	47 Typ	15 Typ	62 Typ		64 Typ	26 Typ			0.04
	Nominal Grain Size 0.070 mm	OS070	46 Typ	14 Typ	65 Typ		58 Typ	15 Typ	32 Typ	13 Typ	0.04
	Nominal Grain Size 0.100 mm	OS100	44 Typ	11 Typ	66 Typ		54 Typ	11 Typ		13 Typ	0.04
	Spring	H08	94 Typ	65 Typ	3 Typ	91 Typ		77 Typ	48 Typ	23 Typ	0.04
Rod	1/2 Hard	H02	70 Typ	52 Typ	330 Typ	80 Typ			42 Typ	22 Typ	1	20
	1/8 Hard	H00	55 Typ	40 Typ	48 Typ	60 Typ			36 Typ		1	6
	Nominal Grain Size 0.050 mm	OS050	48 Typ	16 Typ	65 Typ		65 Typ		34 Typ		1
Tube	Hard	H04	78 Typ	64 Typ	8 Typ	82 Typ		73 Typ				35
	Nominal Grain Size 0.025 mm	OS025	52 Typ	20 Typ	55 Typ		75 Typ	40 Typ
	Nominal Grain Size 0.050 mm	OS050	47 Typ	15 Typ	65 Typ		64 Typ	26 Typ
Wire	1/4 Hard	H01	70 Typ		20 Typ						0.08
	1/8 Hard	H00	58 Typ		35 Typ				38 Typ		0.08
	Extra Hard	H06	124 Typ		4 Typ						0.08
	Nominal Grain Size 0.015 mm	OS015	54 Typ		56 Typ						0.08
	Nominal Grain Size 0.025 mm	OS025	52 Typ		58 Typ						0.08
	Nominal Grain Size 0.035 mm	OS035	50 Typ		60 Typ				34 Typ		0.08
	Nominal Grain Size 0.050 mm	OS050	48 Typ		64 Typ						0.08
	Spring	H08	130 Typ		3 Typ				60 Typ	22 Typ	0.08

Physical Properties

Melting Point - Liquidus°F	1750
Melting Point - Solidus°F	1680
Densitylb/cu in. at 68°F	0.308
Specific Gravity	8.53
Electrical Conductivity% IACS at 68°F	28
Thermal ConductivityBtu/ sq ft/ ft hr/ °F at 68°F	70
Coefficient of Thermal Expansion 68-57210 to -6 power per °F (68 – 572°F)	11.1
Specific Heat CapacityBtu/ lb /°F at 68°F	0.09
Modulus of Elasticity in Tensionksi	16000
Modulus of Rigidityksi	6000

Fabrication Properties

Technique	Suitability
Soldering	Excellent
Brazing	Excellent
Oxyacetylene Welding	Good
Gas Shielded Arc Welding	Fair
Coated Metal Arc Welding	Not Recommended
Spot Weld	Good
Seam Weld	Not Recommended
Butt Weld	Good
Capacity for Being Cold Worked	Excellent
Capacity for Being Hot Formed	Fair

Thermal Properties

Treatment	Minimum*	Maximum*
* Temperature is measured in Fahrenheit.
Annealing	800	1400
Hot Working Temperature	1350	1550

Typical uses

Product Category	Product	Reason Category	Reason
Architecture	Grillwork	Appearance	Color
	Grillwork	Corrosion Resistance	Corrosion Resistance
	Grillwork	Corrosion Resistance	Corrosion Resistance to Fresh Water
	Grillwork	Forming Characteristics	Formability
	Grillwork	Mechanical Properties	Moderate Strength
Automotive	Heater Cord	Corrosion Resistance	Corrosion Resistance
	Heater Cord	Forming Characteristics	Formability
	Heater Cord	Mechanical Properties	Moderate Strength
	Radiators	Corrosion Resistance	Corrosion Resistance
	Radiators	Corrosion Resistance	Corrosion Resistance to Fresh Water
	Radiators	Corrosion Resistance	Corrosion Resistance to Salt Water
	Radiators	Forming Characteristics	Formability
	Radiators	Mechanical Properties	Moderate Strength
	Radiators	Solderability	Solderability
	Tanks	Corrosion Resistance	Corrosion Resistance
	Tanks	Corrosion Resistance	Corrosion Resistance to Chemicals
	Tanks	Corrosion Resistance	Corrosion Resistance to Fresh Water
	Tanks	Corrosion Resistance	Corrosion Resistance to Salt Water
	Tanks	Forming Characteristics	Formability
	Tanks	Mechanical Properties	Moderate Strength
	Tanks	Solderability	Solderability
	Tanks	Welding Characteristics	Weldability
Builders Hardware	Finish Hardware	Corrosion Resistance	Corrosion Resistance
	Finish Hardware	Corrosion Resistance	Corrosion Resistance to Fresh Water
	Finish Hardware	Corrosion Resistance	Corrosion Resistance to Salt Water
	Finish Hardware	Forming Characteristics	Formability
	Finish Hardware	Mechanical Properties	Moderate Strength
	Hinges	Appearance	Color
	Hinges	Corrosion Resistance	Corrosion Resistance
	Hinges	Corrosion Resistance	Corrosion Resistance to Chemicals
	Hinges	Corrosion Resistance	Corrosion Resistance to Fresh Water
	Hinges	Corrosion Resistance	Corrosion Resistance to Salt Water
	Hinges	Forming Characteristics	Formability
	Hinges	Mechanical Properties	Moderate Strength
	Kick Plates	Appearance	Color
	Kick Plates	Corrosion Resistance	Corrosion Resistance
	Kick Plates	Mechanical Properties	Moderate Strength
	Locks	Appearance	Color
	Locks	Corrosion Resistance	Corrosion Resistance
	Locks	Mechanical Properties	Moderate Strength
	Push Plates	Appearance	Color
	Push Plates	Corrosion Resistance	Corrosion Resistance
	Push Plates	Mechanical Properties	Moderate Strength
	Stencils	Forming Characteristics	Formability
	Stencils	Mechanical Properties	Moderate Strength
Electrical	Flashlight Shells	Appearance	Color
	Flashlight Shells	Corrosion Resistance	Corrosion Resistance
	Flashlight Shells	Forming Characteristics	Cold Workability
	Flashlight Shells	Forming Characteristics	Formability
	Flashlight Shells	Mechanical Properties	Moderate Strength
	Lamp Fixtures	Appearance	Color
	Lamp Fixtures	Corrosion Resistance	Corrosion Resistance
	Lamp Fixtures	Forming Characteristics	Formability
	Lamp Fixtures	Mechanical Properties	Moderate Strength
	Reflectors	Appearance	Color
	Reflectors	Corrosion Resistance	Corrosion Resistance
	Reflectors	Forming Characteristics	Formability
	Reflectors	Mechanical Properties	Moderate Strength
	Screw Shells	Corrosion Resistance	Corrosion Resistance
	Screw Shells	Forming Characteristics	Formability
	Screw Shells	Mechanical Properties	Moderate Strength
	Socket Shells	Corrosion Resistance	Corrosion Resistance
	Socket Shells	Forming Characteristics	Formability
Fasteners	Eyelets	Appearance	Color
	Eyelets	Corrosion Resistance	Corrosion Resistance
	Eyelets	Forming Characteristics	Formability
	Eyelets	Mechanical Properties	Moderate Strength
	Fasteners	Conductivity (Electrical)	Electrical Conductivity
	Fasteners	Corrosion Resistance	Corrosion Resistance
	Fasteners	Mechanical Properties	Moderate to High Strength
	Fasteners for Electrical	Conductivity (Electrical)	Electrical Conductivity
	Fasteners for Electrical	Corrosion Resistance	Corrosion Resistance
	Fasteners for Electrical	Mechanical Properties	Moderate to High Strength
	Grommets	Appearance	Color
	Grommets	Corrosion Resistance	Corrosion Resistance
	Grommets	Corrosion Resistance	Corrosion Resistance to Fresh Water
	Grommets	Corrosion Resistance	Corrosion Resistance to Salt Water
	Grommets	Forming Characteristics	Formability
	Grommets	Mechanical Properties	Moderate Strength
	Pins	Appearance	Color
	Pins	Corrosion Resistance	Corrosion Resistance
	Pins	Forming Characteristics	Formability
	Pins	Mechanical Properties	Moderate Strength
	Rivets	Appearance	Color
	Rivets	Corrosion Resistance	Corrosion Resistance
	Rivets	Forming Characteristics	Formability
	Rivets	Mechanical Properties	Moderate Strength
	Screws	Corrosion Resistance	Corrosion Resistance
	Screws	Corrosion Resistance	Corrosion Resistance to Chemicals
	Screws	Corrosion Resistance	Corrosion Resistance to Fresh Water
	Screws	Corrosion Resistance	Corrosion Resistance to Salt Water
	Screws	Forming Characteristics	Formability
	Screws	Mechanical Properties	Moderate Strength
Industrial	Bead Chain	Appearance	Color
	Bead Chain	Corrosion Resistance	Corrosion Resistance
	Bead Chain	Forming Characteristics	Formability
	Bead Chain	Mechanical Properties	Moderate Strength
	Chain	Appearance	Color
	Chain	Corrosion Resistance	Corrosion Resistance
	Chain	Forming Characteristics	Formability
	Chain	Mechanical Properties	Moderate Strength
	Liners	Corrosion Resistance	Corrosion Resistance
	Liners	Corrosion Resistance	Corrosion Resistance to Chemicals
	Liners	Corrosion Resistance	Corrosion Resistance to Fresh Water
	Liners	Corrosion Resistance	Corrosion Resistance to Salt Water
	Liners	Forming Characteristics	Formability
	Liners	Mechanical Properties	Moderate Strength
	Power Cylinders	Corrosion Resistance	Corrosion Resistance
	Power Cylinders	Corrosion Resistance	Corrosion Resistance to Chemicals
	Power Cylinders	Corrosion Resistance	Corrosion Resistance to Fresh Water
	Power Cylinders	Corrosion Resistance	Corrosion Resistance to Salt Water
	Power Cylinders	Forming Characteristics	Cold Workability
	Power Cylinders	Mechanical Properties	Moderate Strength
	Pumps	Corrosion Resistance	Corrosion Resistance
	Pumps	Corrosion Resistance	Corrosion Resistance to Chemicals
	Pumps	Corrosion Resistance	Corrosion Resistance to Fresh Water
	Pumps	Corrosion Resistance	Corrosion Resistance to Salt Water
	Pumps	Forming Characteristics	Formability
	Pumps	Mechanical Properties	Moderate Strength
	Springs	Corrosion Resistance	Corrosion Resistance
	Springs	Forming Characteristics	Formability
	Springs	Mechanical Properties	High Modulus of Elasticity
	Springs	Mechanical Properties	High Strength
Ordnance	Ammunition Components	Mechanical Properties	High Modulus of Elasticity
	Ammunition Components	Mechanical Properties	Moderate Strength
Plumbing	Plumbing Accessories	Appearance	Color
	Plumbing Accessories	Corrosion Resistance	Corrosion Resistance
	Plumbing Accessories	Forming Characteristics	Formability
	Plumbing Accessories	Mechanical Properties	Moderate Strength
	Plumbing Brass Goods	Appearance	Color
	Plumbing Brass Goods	Corrosion Resistance	Corrosion Resistance
	Plumbing Brass Goods	Forming Characteristics	Formability
	Plumbing Brass Goods	Mechanical Properties	Moderate Strength

        If you need product information or price, please fill in your contact information in the form, we will usually contact you within 12 hours. You could also email me info@lyapm.com to get prompt reply.

1. Stock view



2. Processing and Technology for heating processing

Cutting processing      Quenching              Tempering                  Annealing



3. Quality testing

1.      Inspection Institution

Shanghai Fuda Testing Technology Group Co., LTD. Nanjing Branch

Focus on analysis, testing, testing, r & D four service areas. Analysis fields include component analysis, formula analysis, failure analysis, structure analysis, methodology development and validation, raw material quality control/evaluation, consistency evaluation, feature analysis and other directions; The testing field involves physical and chemical properties testing, toxic and harmful substances testing, flame retardant performance testing, reliability testing and other directions; The testing field involves energy spectrum, electron microscope, spectrum, chromatography, mass spectrometry and other directions; The r&d field involves formula development, formula upgrading, formula customisation, cooperative research and development and other directions.

Beijing Zhongke Chemical Technology Research Institute

It is a chemical technology research institution based on scientific research and testing. They adhere to paying equal attention to basic research and applied research, and combining applied research and technology transformation, developing into a comprehensive research institute characterised by "task-oriented disciplines". Approved by the relevant national departments, the company has become a third-party analysis and testing technology service unit, and has obtained CMA qualification certification. It has carried out research and development and design, analysis and testing, test and verification, generic processing, information and intellectual property services, providing public services for innovation of technology-based enterprises. Supported by the government innovation Fund, the institute has been awarded as a national high-tech enterprise.



2.Inspection Machining



   Metal composition testing machine                      Computerised Materials Torsion Testing Machine                Metal bar composite rod bending tensile strength testing machine

       3. Material test certificate

     4. Packaging

    In the steel export activities, we also need to pack the steel to prevent the steel from being scattered in the transportation process. In the hoisting process, it is necessary to lift the steel. So steel is very necessary in the export process. Below is the picture of packaging：

According to the requirements of the state of steel materials, the use of binding, bare, frame, pallet.

Packing standard: according to the following national standard requirements (the parts beyond the requirements will be specified separately)

GB／T191 packaging-pictorial marking for handling of goods

GB／T4857 (all parts) basic test for transport packages

GB／T4879 rustproof packaging

GB／T5048 damp-proof packing

GB／T7350water-proof packing

GB／T8166 Package cushioning design

GB/T4892-1996  Hard straight square transport packaging size series

GB/T13201-91 Cylinder transport package size series

 GB/T16471-1996Design and make the size limit of transport package

5. Logistic



1. Company profile

Luoyue Precision Metal established in 2018, is a leading Stockists and global distributor for Metal Raw Materials like Steel/Aluminum/ Stainless steel/Copper/ Nickel Rods, Bars, Plates, Sheets,Pipes, fittings, fasteners, Inconel alloys, Wire and Wire-Mesh to customers from aerospace, automotive, electronics, precision manufacturing, ordnance, marine, shipbuilding, oil & gas, power plant and construction.

The company has a high-precision, high-efficiency modern processing site, CNC machine tools and complete testing and inspection technology, and introduces international advanced technologies.

           2. Certificates. (Business certificate/ISO9001/Trading certificate/SGS/FormE)

                  .

          3. Our customers

                 Customer visits

           4. Past Inquiry

                  .

   1.Customer Rating



FAQ
1. Q: Are you a manufacturer?
 A:No, we are not manufacturers. We have our own warehouse and our own company. I believe we will be the most suitable supplier for you.
2. Could we visit your factory?
 A: Sure, we welcome you to visit the factory , check our production lines and know more about our strength and quality.
3. Q: Do you have quality control system?
 A: Yes, we have ISO, BV, SGS certifications and our own quality control laboratory.
4. Q: Can you arrange the shipment for us?
 A: Yes, we have designated sea freight and railway freight forwarders with decades of experiences and we get the best  price with earliest vessel and professional service.
5. Q: How long is the delivery time?
 A: Generally it is 7 days if we have the exact goods in our stock. If not, it will take around 15-20 days to get goods ready for delivery.
6. Q: Can I get some samples?
 A: We are glad to provide free samples to you, but we do not offer the freight.
7. Q: What is your after-sale service?
 A: We provide after-sale service and offer 100% guarantee on our products.
8. Q: What is your MOQ?
 A: 2 Tons

Contact us
