CuSn8 is a solid solution strengthened copper alloy (bronze) with 8% tin. The high tin content results in high strength and good spring properties at an adequate conductivity. The alloy is wear-resistant, has very good corrosion resistance and can be readily soldered. Moreover CuSn8 has good sliding properties.

Product Name	Copper Sheet
Material	Copper
Standard	ASTM, AISI, JIS, DIN, GB, EN
Grade	C10100,C10200,C10300,C10400,C10500,C10700,C10800,C10910,C10920,C10930, C11000,C11300,C11400,C11500,C11600,C12000,C12200,C12300,C12500,C14200, C14420,C14500,C14510,C14520,C14530,C17200,C19200,C21000,C23000,C26000, C27000,C27400,C28000,C33000,C33200,C37000,C44300,C44400,C44500,C60800, C63020,C65500,C68700,C70400, C70620,C71000,C71500,C71520,C71640,C72200 T1,T2,T3,TU1,TU0,TU2,TP1,TP2,TAg0.1,
Shape	Flat plate
Temper	O-H112; T3-T8; T351-T851
Size	thickness 0.3mm~100mm; Width 50mm~2500mm; Length 1000mm~12000mm
Surface	Mill finish, polished, anodizing, brushing, sand blasting, powder coating,etc
Payment terms	T/T,L/C,western union, Paypal
Price terms	CFR,FOB,CIF,Ex-work,CNF
Application	1)Further making utensil. 2)Solar reflective film 3)The appearance of the building 4)Interior decorating:ceilings,walls,etc. 5)Furniture cabinets 6)Elevator decoraction 7)Signs,nameplate,bags making. 8)Decorated inside and outside the car 9)Household appliances:refrigerators,microwave ovens,audio equipment,etc. 10)The consumer electronics:mobile phones,digital cameras,MP3,U disk,etc.
Package	Standard export seaworthy package or as required.
Contact	If you have any question,please feel free to contact me.

Mechanical

Property	Temperature	Value
Elastic modulus	23.0 °C	115 GPa
Elongation A5	23.0 °C	6 %
Hardness, Brinell	23.0 °C	220 [-]
Tensile strength	23.0 °C	690 MPa
Yield strength Rp0.2	23.0 °C	640 MPa

Thermal

Property	Temperature	Value
Coefficient of thermal expansion	23.0 °C	1.85E-5 1/K
Thermal conductivity	23.0 °C	67 W/(m·K)

Electrical

Property	Temperature	Value
Electrical conductivity	23.0 °C	7.50E+6 S/m

Chemical properties

Mechanical Properties

Round Wire

TEMPER NAME	TEMPER CODE	TENSILE STRENGTH (ksi)		MILL LIMITS
		MIN	MAX
Annealed		53	68	.0010 - .1285 inch
1/4 Hard	H01	74	91
1/2 Hard	H02	95	115
3/4 Hard	H03	113	135
Hard	H04	125	150

Square Wire

TEMPER NAME	TEMPER CODE	TENSILE STRENGTH (ksi)		MILL LIMITS
		MIN	MAX
Annealed		53	68	.0100 - .0808 inch
1/4 Hard	H01	74	91
1/2 Hard	H02	95	115
3/4 Hard	H03	113	135
Hard	H04	125	150

Rolled Flat

TEMPER NAME	TEMPER CODE	TENSILE STRENGTH (ksi)		MILL LIMITS
		MIN	MAX
Annealed		53	67	Thickness: .0100 - .0500 inch Width: .0150 - .2500 inch
1/2 Half Hard	H02	69	84
Hard	H04	85	100
Extra Hard	H06	97	112
Spring	H08	105	119
Extra Spring	H10	110	122

Physical Properties

Melting Point (Liquidis)	1880°F
Melting Point (Solidus)	1620°F
Density	0.318 lbs/cu in
Electrical Resistivity (Annealed)	79.8 Ω⋅cmil/ft @ 68°F
Electrical Conductivity (Annealed)	13% IACS @ 68°F
Thermal Conductivity (Solutionized-Aged)	36 Btu ft/sq ft hr °F @ 68°F
Coefficient of Thermal Expansion	0.0000101°F (68-572°F)
Modulus of Elasticity (Tension)	16000 ksi
Modulus of Rigidity	6000 ksi

Main fields of application

AMPCO® 18 is used mainly in:

• Plastics Tooling & Mold Making
• Steel Mills
• Tube Bending
• Tube Forming
• Wear & Corrosion Resistance
• Watch cases

 If you need product information or price, please fill in your contact information in the form, we will usually contact you within 12 hours. You could also email me info@lyapm.com to get prompt reply.

1. Stock view

Thickness:	0.1-300mm,etc	Length:	100-12000mm,or as required
Width:	10-3000mm,etc	Standard:	ASTM,AISI,JIS,GB, DIN,EN
Surface finish	mill,polished,bright,oiled,hair line,brush,mirror,sand blast,or as required.
Certification:	ISO, SGS,BV	price terms	FOB,CRF,CIF,EXW  all acceptable
Loading port	any port in China	Delivery Detail	inventory About 5-7; custom-made 25-30,According to order's quantity.
Copper	GB
	T1,T2,T3,TU1,TU0,TU2,TP1,TP2,TAg0.1,
	ASTM
	C10100,C10200,C10300,C10400,C10500,C10700,C10800,C10910,C10920,
	C10930,C10940,C11000,C11300,C11400,C11500,C11600,C12000,C12200,
	C12300,C12500,C14200,C14420,C14500,C14510,C14520,C14530,C14700,
	C15100,C15500,C16200,C16500,C17000,C17200,C17300,C17410,C17450,
	C17460,C17500,C17510,C18700,C19010,C19025,C19200,C19210,C19400,
	C19500,C19600,C19700,
	JIS
	C1011,C1020,C1100,C1201,C1220,C1221,C1401,C1700,C1720,C1990,



2. Processing and Technology for heating processing

Cutting processing      Quenching              Tempering                  Annealing



3. Quality testing

1.      Inspection Institution

Shanghai Fuda Testing Technology Group Co., LTD. Nanjing Branch

Focus on analysis, testing, testing, r & D four service areas. Analysis fields include component analysis, formula analysis, failure analysis, structure analysis, methodology development and validation, raw material quality control/evaluation, consistency evaluation, feature analysis and other directions; The testing field involves physical and chemical properties testing, toxic and harmful substances testing, flame retardant performance testing, reliability testing and other directions; The testing field involves energy spectrum, electron microscope, spectrum, chromatography, mass spectrometry and other directions; The r&d field involves formula development, formula upgrading, formula customisation, cooperative research and development and other directions.

Beijing Zhongke Chemical Technology Research Institute

It is a chemical technology research institution based on scientific research and testing. They adhere to paying equal attention to basic research and applied research, and combining applied research and technology transformation, developing into a comprehensive research institute characterised by "task-oriented disciplines". Approved by the relevant national departments, the company has become a third-party analysis and testing technology service unit, and has obtained CMA qualification certification. It has carried out research and development and design, analysis and testing, test and verification, generic processing, information and intellectual property services, providing public services for innovation of technology-based enterprises. Supported by the government innovation Fund, the institute has been awarded as a national high-tech enterprise.



2.Inspection Machining



   Metal composition testing machine                      Computerised Materials Torsion Testing Machine                Metal bar composite rod bending tensile strength testing machine

       3. Material test certificate

     4. Packaging

    In the steel export activities, we also need to pack the steel to prevent the steel from being scattered in the transportation process. In the hoisting process, it is necessary to lift the steel. So steel is very necessary in the export process. Below is the picture of packaging：

According to the requirements of the state of steel materials, the use of binding, bare, frame, pallet.

Packing standard: according to the following national standard requirements (the parts beyond the requirements will be specified separately)

GB／T191 packaging-pictorial marking for handling of goods

GB／T4857 (all parts) basic test for transport packages

GB／T4879 rustproof packaging

GB／T5048 damp-proof packing

GB／T7350water-proof packing

GB／T8166 Package cushioning design

GB/T4892-1996  Hard straight square transport packaging size series

GB/T13201-91 Cylinder transport package size series

 GB/T16471-1996Design and make the size limit of transport package

5. Logistic



1. Company profile

Luoyue Precision Metal established in 2018, is a leading Stockists and global distributor for Metal Raw Materials like Steel/Aluminum/ Stainless steel/Copper/ Nickel Rods, Bars, Plates, Sheets,Pipes, fittings, fasteners, Inconel alloys, Wire and Wire-Mesh to customers from aerospace, automotive, electronics, precision manufacturing, ordnance, marine, shipbuilding, oil & gas, power plant and construction.

The company has a high-precision, high-efficiency modern processing site, CNC machine tools and complete testing and inspection technology, and introduces international advanced technologies.

           2. Certificates. (Business certificate/ISO9001/Trading certificate/SGS/FormE)

                  .

          3. Our customers

                 Customer visits

           4. Past Inquiry

                  .

FAQ
1. Q: Are you a manufacturer?
 A:No, we are not manufacturers. We have our own warehouse and our own company. I believe we will be the most suitable supplier for you.
2. Could we visit your factory?
 A: Sure, we welcome you to visit the factory , check our production lines and know more about our strength and quality.
3. Q: Do you have quality control system?
 A: Yes, we have ISO, BV, SGS certifications and our own quality control laboratory.
4. Q: Can you arrange the shipment for us?
 A: Yes, we have designated sea freight and railway freight forwarders with decades of experiences and we get the best  price with earliest vessel and professional service.
5. Q: How long is the delivery time?
 A: Generally it is 7 days if we have the exact goods in our stock. If not, it will take around 15-20 days to get goods ready for delivery.
6. Q: Can I get some samples?
 A: We are glad to provide free samples to you, but we do not offer the freight.
7. Q: What is your after-sale service?
 A: We provide after-sale service and offer 100% guarantee on our products.
8. Q: What is your MOQ?
 A: 2 Tons
