C72500-Luoyue Precision Metal

COPPER-NICKEL-TIN C72500

COMPOSITION
COPPER-NICKEL-TIN C72500

ELEMENT PERCENT

NOMINAL MINIMUM MAXIMUM

Copper
88.2
–
–

Lead
– – .05

Iron – – .60

Zinc – – .50

Nickel 9.5 8.5 10.5

Manganese – – .20

Tin 2.3 1.8 2.8

Copper plus elements specified –
99.8

–

PHYSICAL PROPERTIES
COPPER-NICKEL-TIN C72500

HEAT TREATED CONDITION ENGLISH UNITS METRIC UNITS

Melting Range 1940-2065°F 1060-1130°C

Density .321 lb/cu in. @ 68°F 8.89 gm/cm@ 20°C

Specific Gravity 8.89 8.89

Coefficient of Thermal
Expansion .0000092 per °F (68-572°F) .0000165 per °C (20-300°C)

Thermal Conductivity 31 BTU/sq ft/ft/hr/°F @ 68°F .13 cal/sq cm/cm/sec/°C @ 20°C

Electrical Resistivity 94.3 Ohms circ mil per ft @ 68°F 15.7 microhm – cm @ 20°C

Electrical Conductivity 11% Copper IACS @ 68°F .064 megohm cm @ 20°C

Modulus of Elasticity
(tension) 20,000 KSI 14,100 kg/sq mm

Modulus of Rigidity
(torsion) 7,500 KSI 5,200 kg/sq mm

Annealing Temperature 1200-1475°F 650-800°C

MECHANICAL PROPERTIES
COPPER-NICKEL-TIN C72500

For Round and Square Wire

DESIGNATION TENSILE STRENGTH YIELD STRENGTH
.2% Offset † % †
ELONGATION
in 10 in.

STD FORMER KSI*
nominal MPa**
nominal KSI* MPa**

– Annealed (0.15mm) 60 410 25 170 35

H01 Quarter Hard (1/4H) 80 550 – – –

H02 Half Hard (1/2H) 90 620 – – –

H06 Extra Hard (XH) 100 690 – – –

H14 Super Spring 120 8.30 – – –

Range – apply ą5 KSI to hardest material rising to ą8 KSI on annealed.

MECHANICAL PROPERTIES
COPPER-NICKEL-TIN C72500

For Rolled Flat Wire other than Square

DESIGNATION TENSILE STRENGTH
NOMINAL YIELD STRENGTH .2% Offset %
ELONGATION IN 10 in. †

STD FORMER KSI* MPa** KSI* MPa**

– Annealed (0.15mm) 55 380 22 151 35

H01 Quarter Hard (1/4H) 55-75 380-515 58 399 18

H02 Half Hard (1/2H) 65-80 450-550 69 475 6

– Three Quarter Hard (3/4H) 77 – 75 517 5

H04 Extra Hard (XH) 80-95 550-655 86 592 2

H08 Spring 85-100 585-690 90 620 1

H14 Super Spring 100-125 690-860 108 745 1

* 1 KSI equals 1,000 PSI

** 1 KSI equals 6.894,757 MPa

MPa equals Megapascal

†Values for reference only.

COPPER-NICKEL-TIN C72500

If you need product information or price, please fill in your contact information in the form, we will usually contact you within 12 hours. You could also email me info@lyapm.com to get prompt reply.

1. Stock view



2. Processing and Technology for heating processing

Cutting processing   Quenching   Tempering Annealing



3. Quality testing

1.      Inspection Institution

Shanghai Fuda Testing Technology Group Co., LTD. Nanjing Branch

Focus on analysis, testing, testing, r & D four service areas. Analysis fields include component analysis, formula analysis, failure analysis, structure analysis, methodology development and validation, raw material quality control/evaluation, consistency evaluation, feature analysis and other directions; The testing field involves physical and chemical properties testing, toxic and harmful substances testing, flame retardant performance testing, reliability testing and other directions; The testing field involves energy spectrum, electron microscope, spectrum, chromatography, mass spectrometry and other directions; The r&d field involves formula development, formula upgrading, formula customisation, cooperative research and development and other directions.

Beijing Zhongke Chemical Technology Research Institute

It is a chemical technology research institution based on scientific research and testing. They adhere to paying equal attention to basic research and applied research, and combining applied research and technology transformation, developing into a comprehensive research institute characterised by "task-oriented disciplines". Approved by the relevant national departments, the company has become a third-party analysis and testing technology service unit, and has obtained CMA qualification certification. It has carried out research and development and design, analysis and testing, test and verification, generic processing, information and intellectual property services, providing public services for innovation of technology-based enterprises. Supported by the government innovation Fund, the institute has been awarded as a national high-tech enterprise.



2.Inspection Machining

   Metal composition testing machine   Computerised Materials Torsion Testing Machine   Metal bar composite rod bending tensile strength testing machine

3. Material test certificate

4. Packaging

  In the steel export activities, we also need to pack the steel to prevent the steel from being scattered in the transportation process. In the hoisting process, it is necessary to lift the steel. So steel is very necessary in the export process. Below is the picture of packaging：



According to the requirements of the state of steel materials, the use of binding, bare, frame, pallet.

Packing standard: according to the following national standard requirements (the parts beyond the requirements will be specified separately)

GB／T191 packaging-pictorial marking for handling of goods

GB／T4857 (all parts) basic test for transport packages

GB／T4879 rustproof packaging

GB／T5048 damp-proof packing

GB／T7350water-proof packing

GB／T8166 Package cushioning design

GB/T4892-1996  Hard straight square transport packaging size series

GB/T13201-91 Cylinder transport package size series

GB/T16471-1996Design and make the size limit of transport package

5. Logistic



By SEA By Air By Express

If you need product information or price, please fill in your contact information in the form below, we will usually contact you within 12 hours. You could also email me info@lyapm.com to get prompt reply.

1. Company profile

Luoyue Precision Metal established in 2018, is a leading Stockists and global distributor for Metal Raw Materials like Steel/Aluminum/ Stainless steel/Copper/ Nickel Rods, Bars, Plates, Sheets,Pipes, fittings, fasteners, Inconel alloys, Wire and Wire-Mesh to customers from aerospace, automotive, electronics, precision manufacturing, ordnance, marine, shipbuilding, oil & gas, power plant and construction.

The company has a high-precision, high-efficiency modern processing site, CNC machine tools and complete testing and inspection technology, and introduces international advanced technologies.

2. Certificates. (Business certificate/ISO9001/Trading certificate/SGS/FormE)

.

3. Our customers

Customer visits

4. Past Inquiry

.

If you need product information or price, please fill in your contact information in the form below, we will usually contact you within 12 hours. You could also email me info@lyapm.com to get prompt reply.

Customer Feedback:

Comments

HOT FAQ:

Q1. Where is your factory ?

A1: Our company’s processing center is located in Shanghai, China.Which is well equipped with kinds of machines, such as laser cutting machine,mirror polishing machine and so on.We can provide a wide range of personalized services according to the customers’ needs.

Q2. What are your company's main products ?

A2: We are professional one-stop meta supplier for Aluminium/ steel/ stainless steel/ copper etc.

Q3. How do you control quality ?

A3: Mill Test Certification is supplied with shipment, Third Party Inspection is available.

Q4. What are the advantages of your company ?

A4: We have many professionals, technical personnel, more competitive prices and best after-dales service than other stainless steel companies.

Q5. How many coutries you already exported ?

A5: Exported to more than 50 countries mainly from America, Russia, UK, Kuwait, Egypt,Turkey, Jordan, India, etc. We are based in Shanghai, China, start from 2019,sell to Southeast Asia(50.00%),South America(10.00%),North America(5.00%),Eastern Europe(5.00%),Eastern Asia(5.00%),Northern Europe(5.00%),Domestic Market(15.00%),Mid East(10.00%). There are total about 11-50 people in our office.

Q6. Can you provide sample ?

A6: Small samples in store and can provide the samples for free.

Customized samples will take about 5-7days.

Q7Could we visit your factory?

A7: Sure, we welcome you to visit the factory , check our production lines and know more about our strength and quality.

Q8: Do you have quality control system?

A8: Yes, we have ISO, BV, SGS certifications and our own quality control laboratory.

Q9: Can you arrange the shipment for us?

A9: Yes, we have designated sea freight and railway freight forwarders with decades of experiences and we get the best price with earliest vessel and professional service.

Q10: How long is the delivery time?

A10: Generally it is 7 days if we have the exact goods in our stock. If not, it will take around 15-20 days to get goods ready for delivery.

Q11: Can I get some samples?

A11: We are glad to provide free samples to you, but we do not offer the freight.

Q12: What is your after-sale service?

A12: We provide after-sale service and offer 100% guarantee on our products.

Q13: What is your MOQ?

A13: Depend on the request material, sometimes for customized one have MOQ.

Q14: why should you buy from us not from other suppliers?

Luoyue precision metals (Shanghai) Co., Ltd. is located in Shanghai, China. It is one of the most professional metal material suppliers in China, providing nearly 100 kinds of metal materials, from raw materials to CNC processing

Q15: what services can we provide?

Accepted Delivery Terms: FOB, CFR, CIF, EXW, CIP, DDP, Express Delivery

Accepted Payment Currency:USD,EUR,JPY,CAD,GBP,CNY;

Accepted Payment Type: T/T,L/C,D/P D/A

Language Spoken:English,Chinese,Spanish

Supply Ability

500 Ton/Tons per Month

Packaging & Delivery

Airworthy package. Waterproof cloth, wooden case, craft paper and steel belt packing.

Port: shanghai

Exhibition

Production Workshop

Package & Shipping

Contact us

COMPOSITION COPPER-NICKEL-TIN C72500
ELEMENT	PERCENT
ELEMENT	NOMINAL	MINIMUM	MAXIMUM
Copper	88.2	–	–
Lead	–	–	.05
Iron	–	–	.60
Zinc	–	–	.50
Nickel	9.5	8.5	10.5
Manganese	–	–	.20
Tin	2.3	1.8	2.8
Copper plus elements specified	–	99.8	–

PHYSICAL PROPERTIES COPPER-NICKEL-TIN C72500
HEAT TREATED CONDITION	ENGLISH UNITS	METRIC UNITS
Melting Range	1940-2065°F	1060-1130°C
Density	.321 lb/cu in. @ 68°F	8.89 gm/cm@ 20°C
Specific Gravity	8.89	8.89
Coefficient of Thermal Expansion	.0000092 per °F (68-572°F)	.0000165 per °C (20-300°C)
Thermal Conductivity	31 BTU/sq ft/ft/hr/°F @ 68°F	.13 cal/sq cm/cm/sec/°C @ 20°C
Electrical Resistivity	94.3 Ohms circ mil per ft @ 68°F	15.7 microhm – cm @ 20°C
Electrical Conductivity	11% Copper IACS @ 68°F	.064 megohm cm @ 20°C
Modulus of Elasticity (tension)	20,000 KSI	14,100 kg/sq mm
Modulus of Rigidity (torsion)	7,500 KSI	5,200 kg/sq mm
Annealing Temperature	1200-1475°F	650-800°C

MECHANICAL PROPERTIES COPPER-NICKEL-TIN C72500
For Round and Square Wire
DESIGNATION		TENSILE STRENGTH		YIELD STRENGTH .2% Offset †		% † ELONGATION in 10 in.
STD	FORMER	KSI* nominal	MPa** nominal	KSI*	MPa**	% † ELONGATION in 10 in.
–	Annealed (0.15mm)	60	410	25	170	35
H01	Quarter Hard (1/4H)	80	550	–	–	–
H02	Half Hard (1/2H)	90	620	–	–	–
H06	Extra Hard (XH)	100	690	–	–	–
H14	Super Spring	120	8.30	–	–	–
Range – apply ą5 KSI to hardest material rising to ą8 KSI on annealed.

MECHANICAL PROPERTIES COPPER-NICKEL-TIN C72500
For Rolled Flat Wire other than Square
DESIGNATION		TENSILE STRENGTH NOMINAL		YIELD STRENGTH .2% Offset		% ELONGATION IN 10 in. †
STD	FORMER	KSI*	MPa**	KSI*	MPa**	% ELONGATION IN 10 in. †
–	Annealed (0.15mm)	55	380	22	151	35
H01	Quarter Hard (1/4H)	55-75	380-515	58	399	18
H02	Half Hard (1/2H)	65-80	450-550	69	475	6
–	Three Quarter Hard (3/4H)	77	–	75	517	5
H04	Extra Hard (XH)	80-95	550-655	86	592	2
H08	Spring	85-100	585-690	90	620	1
H14	Super Spring	100-125	690-860	108	745	1
