Introduction

Aluminium / aluminum alloys are very sensitive to high temperatures. Their strength can be increased when they are subjected to subzero temperatures. They have strong corrosion resistance and high ductility.

The following datasheet gives an overview of the aluminium / aluminum 6070 alloy.

Chemical Composition

The chemical composition of aluminium / aluminum 6070 alloy is outlined in the following table.

Element	Content (%)
Aluminium / aluminum, Al	97
Silicon, Si	1.40
Magnesium, Mg	0.80
Manganese, Mn	0.70
Copper, Cu	0.28

Physical Properties

The physical properties of aluminium / aluminum 6070 alloy are tabulated below.

Properties	Metric	Imperial
Density	2.6-2.8 g/cm3	0.0939- 0.101 lb/in3

Mechanical Properties

The mechanical properties of aluminium / aluminum 6070 alloy are outlined in the following table.

Properties	Metric	Imperial
Tensile strength	145 MPa	21031 psi
Yield strength	69 MPa	10008 psi
Shear strength	97 MPa	14069 psi
Fatigue strength	62 MPa	8993 psi
Elastic modulus	70-80 GPa	10153-11603 ksi
Poisson's ratio	0.33	0.33
Elongation	20%	20%
Hardness	35	35

Thermal Properties

The thermal properties of the aluminium / aluminum 6070 alloy are given in the following table.

Properties		Conditions
		Temp	Treatment
Thermal conductivity	175 W/mK	25ºC/77ºF	T6

Other Designations

Other designations equivalent to aluminium / aluminum 6070 alloy include ASTM B221.

Applications

Aluminium / aluminum 6070 alloy is used in manufacturing pipelines and heavy duty welded structures.
