Chemical Composition

	Elements
	Cu(1)	Pb	Zn	Fe
(1) Cu + Sum of Named Elements 99.8% min.
Min (%)	94.0
Max (%)	96.0	0.05	Rem	0.05

Mechanical Properties *

Form	Temper	Temper Code	Tensile Strength (ksi)	YS-0.5% Ext (ksi)	Elongation (%)	Rockwell B scale	Rockwell F scale	Rockwell 30T scale	Shear Strength (ksi)	Torsion Modulus (ksi)	Ultimate Tensile Strength in Shear (ksi)	Section Size (in)
* Measured at room temperature, 68°F (20°C).
Flat Products	1/2 Hard	H02	48 Typ	40 Typ	12 Typ	52 Typ		54 Typ	34 Typ			0.04
	1/4 Hard	H01	42 Typ	32 Typ	25 Typ						32 Typ	0.04
	1/4 Hard	H01	42 Typ	32 Typ	25 Typ	38 Typ		44 Typ	32 Typ			0.04
	Extra Hard	H06	61 Typ	55 Typ	4 Typ	70 Typ		64 Typ	39 Typ	6.4 Typ		0.04
	Hard	H04	56 Typ	50 Typ	5 Typ	64 Typ		60 Typ	37 Typ			0.04
	Hard	H04	56 Typ	50 Typ	5 Typ						37 Typ	0.04
	Nominal Grain Size 0.015 mm	OS015	38 Typ	14 Typ	42 Typ		60 Typ	15 Typ	30 Typ			0.04
	Nominal Grain Size 0.035 mm	OS035	35 Typ	11 Typ	45 Typ		52 Typ	4 Typ	28 Typ			0.04
	Nominal Grain Size 0.050 mm	OS050	34 Typ	10 Typ	45 Typ		46 Typ					0.04
	Spring	H08	64 Typ	58 Typ	4 Typ						40 Typ	0.04
	Spring	H08	64 Typ	58 Typ	4 Typ	73 Typ		66 Typ	40 Typ			0.04

Physical Properties

Melting Point - Liquidus°F	1950
Melting Point - Solidus°F	1920
Densitylb/cu in. at 68°F	0.32
Specific Gravity	8.86
Electrical Conductivity% IACS at 68°F	56
Thermal ConductivityBtu/ sq ft/ ft hr/ °F at 68°F	135
Coefficient of Thermal Expansion 68-57210 to -6 power per °F (68 – 572°F)	10
Specific Heat CapacityBtu/ lb /°F at 68°F	0.09
Modulus of Elasticity in Tensionksi	17000
Modulus of Rigidityksi	6400

Fabrication Properties

Technique	Suitability
Soldering	Excellent
Brazing	Excellent
Oxyacetylene Welding	Good
Gas Shielded Arc Welding	Good
Coated Metal Arc Welding	Not Recommended
Spot Weld	Not Recommended
Seam Weld	Not Recommended
Butt Weld	Good
Capacity for Being Cold Worked	Excellent
Capacity for Being Hot Formed	Good
Machinability Rating	20

Typical uses

Product Category	Product	Reason Category	Reason
Architecture	Ornamental Trim	Appearance	Appearance
	Ornamental Trim	Corrosion Resistance	Corrosion Resistance
	Ornamental Trim	Mechanical Properties	Moderate Strength
	Ornamental Trim	Plating Characteristics	Plateable
Consumer	Emblems	Appearance	Appearance
	Emblems	Corrosion Resistance	Corrosion Resistance
	Emblems	Forming Characteristics	Formability
	Emblems	Mechanical Properties	Moderate Strength
	Emblems	Plating Characteristics	Plateable
	Jewelry	Appearance	Appearance
	Jewelry	Corrosion Resistance	Corrosion Resistance
	Jewelry	Forming Characteristics	Formability
	Jewelry	Mechanical Properties	Moderate Strength
	Jewelry	Plating Characteristics	Plateable
	Plaques, Medallions	Appearance	Appearance
	Plaques, Medallions	Finishing Characteristics	Accepts Lacquers
	Plaques, Medallions	Forming Characteristics	Coinability
	Plaques, Medallions	Forming Characteristics	Formability
	Plaques, Medallions	Plating Characteristics	Base for Gold Plate
Electrical	Connectors	Conductivity (Electrical)	Electrical Conductivity
	Connectors	Conductivity (Thermal)	Thermal Conductivity
	Connectors	Corrosion Resistance	Corrosion Resistance
	Connectors	Forming Characteristics	Formability
	Connectors	Mechanical Properties	Moderate Strength
	Rotor Bars, AC Motors	Brazing Characteristics	Brazability
	Rotor Bars, AC Motors	Conductivity (Electrical)	Electrical Resistivity
	Rotor Bars, AC Motors	Mechanical Properties	Moderate Strength
Fasteners	Fasteners	Appearance	Appearance
	Fasteners	Corrosion Resistance	Corrosion Resistance
	Fasteners	Forming Characteristics	Formability
	Fasteners	Mechanical Properties	Moderate Strength
Industrial	Base for Gold Plate	Mechanical Properties	Moderate Strength
	Base for Gold Plate	Plating Characteristics	Plateable
	Base for Vitreous Enamel	Mechanical Properties	Moderate Strength
	Base for Vitreous Enamel	Plating Characteristics	Plateable
Ordnance	Bullet Jackets	Corrosion Resistance	Corrosion Resistance
	Bullet Jackets	Forming Characteristics	Formability
	Bullet Jackets	Mechanical Properties	Moderate Strength
	Firing Pin Support Shells	Corrosion Resistance	Corrosion Resistance
	Firing Pin Support Shells	Forming Characteristics	Formability
	Firing Pin Support Shells	Mechanical Properties	Moderate Strength
	Fuse Caps	Corrosion Resistance	Corrosion Resistance
	Fuse Caps	Forming Characteristics	Formability
	Fuse Caps	Mechanical Properties	Moderate Strength
	Fuse Caps	Plating Characteristics	Plateable
	Primers	Corrosion Resistance	Corrosion Resistance
	Primers	Forming Characteristics	Formability
	Primers	Mechanical Properties	Moderate Strength
	Small Arm Ammunition:Primer Caps, Bullet Jackets	Corrosion Resistance	Corrosion Resistance
	Small Arm Ammunition:Primer Caps, Bullet Jackets	Corrosion Resistance	Stress Corrosion Cracking Resistance
	Small Arm Ammunition:Primer Caps, Bullet Jackets	Forming Characteristics	Formability
	Small Arm Ammunition:Primer Caps, Bullet Jackets	Mechanical Properties	Moderate Strength
Other	Coins	Appearance	Appearance
	Coins	Forming Characteristics	Coinability
	Coins	Plating Characteristics	Plateable
	Medals	Appearance	Appearance
	Medals	Corrosion Resistance	Corrosion Resistance
	Medals	Forming Characteristics	Formability
	Medals	Mechanical Properties	Moderate Strength
	Medals	Plating Characteristics	Plateable
	Tokens	Corrosion Resistance	Corrosion Resistance
	Tokens	Forming Characteristics	Coinability
	Tokens	Forming Characteristics	Formability
	Tokens	Mechanical Properties	Moderate Strength

Applicable Specifications

Form	Specific Sub-Form	Application	System	Standard	Description
Bar			ASTM	B36/B36M	BRASS PLATE, SHEET, STRIP AND ROLLED BAR
			SAE	J463	WROUGHT COPPER AND COPPER ALLOYS
			SAE	J461	WROUGHT AND CAST COPPER ALLOYS
Plate			ASTM	B36/B36M	BRASS PLATE, SHEET, STRIP AND ROLLED BAR
Rod, Bar & Shapes			ASTM	B927/B927M	BRASS ROD, BAR, AND SHAPES
Sheet			ASTM	B36/B36M	BRASS PLATE, SHEET, STRIP AND ROLLED BAR
			SAE	J461	WROUGHT AND CAST COPPER ALLOYS
			SAE	J463	WROUGHT COPPER AND COPPER ALLOYS
Strip			SAE	J463	WROUGHT COPPER AND COPPER ALLOYS
			ASTM	B36/B36M	BRASS PLATE, SHEET, STRIP AND ROLLED BAR
			SAE	J461	WROUGHT AND CAST COPPER ALLOYS
Tube			ASTM	B587	WELDED BRASS TUBE
Wire			ASTM	B134/B134M	BRASS WIRE

Typical uses

Product Category	Product	Reason Category	Reason
Architecture	Ornamental Trim	Appearance	Appearance
	Ornamental Trim	Corrosion Resistance	Corrosion Resistance
	Ornamental Trim	Mechanical Properties	Moderate Strength
	Ornamental Trim	Plating Characteristics	Plateable
Consumer	Emblems	Appearance	Appearance
	Emblems	Corrosion Resistance	Corrosion Resistance
	Emblems	Forming Characteristics	Formability
	Emblems	Mechanical Properties	Moderate Strength
	Emblems	Plating Characteristics	Plateable
	Jewelry	Appearance	Appearance
	Jewelry	Corrosion Resistance	Corrosion Resistance
	Jewelry	Forming Characteristics	Formability
	Jewelry	Mechanical Properties	Moderate Strength
	Jewelry	Plating Characteristics	Plateable
	Plaques, Medallions	Appearance	Appearance
	Plaques, Medallions	Finishing Characteristics	Accepts Lacquers
	Plaques, Medallions	Forming Characteristics	Coinability
	Plaques, Medallions	Forming Characteristics	Formability
	Plaques, Medallions	Plating Characteristics	Base for Gold Plate
Electrical	Connectors	Conductivity (Electrical)	Electrical Conductivity
	Connectors	Conductivity (Thermal)	Thermal Conductivity
	Connectors	Corrosion Resistance	Corrosion Resistance
	Connectors	Forming Characteristics	Formability
	Connectors	Mechanical Properties	Moderate Strength
	Rotor Bars, AC Motors	Brazing Characteristics	Brazability
	Rotor Bars, AC Motors	Conductivity (Electrical)	Electrical Resistivity
	Rotor Bars, AC Motors	Mechanical Properties	Moderate Strength
Fasteners	Fasteners	Appearance	Appearance
	Fasteners	Corrosion Resistance	Corrosion Resistance
	Fasteners	Forming Characteristics	Formability
	Fasteners	Mechanical Properties	Moderate Strength
Industrial	Base for Gold Plate	Mechanical Properties	Moderate Strength
	Base for Gold Plate	Plating Characteristics	Plateable
	Base for Vitreous Enamel	Mechanical Properties	Moderate Strength
	Base for Vitreous Enamel	Plating Characteristics	Plateable
Ordnance	Bullet Jackets	Corrosion Resistance	Corrosion Resistance
	Bullet Jackets	Forming Characteristics	Formability
	Bullet Jackets	Mechanical Properties	Moderate Strength
	Firing Pin Support Shells	Corrosion Resistance	Corrosion Resistance
	Firing Pin Support Shells	Forming Characteristics	Formability
	Firing Pin Support Shells	Mechanical Properties	Moderate Strength
	Fuse Caps	Corrosion Resistance	Corrosion Resistance
	Fuse Caps	Forming Characteristics	Formability
	Fuse Caps	Mechanical Properties	Moderate Strength
	Fuse Caps	Plating Characteristics	Plateable
	Primers	Corrosion Resistance	Corrosion Resistance
	Primers	Forming Characteristics	Formability
	Primers	Mechanical Properties	Moderate Strength
	Small Arm Ammunition:Primer Caps, Bullet Jackets	Corrosion Resistance	Corrosion Resistance
	Small Arm Ammunition:Primer Caps, Bullet Jackets	Corrosion Resistance	Stress Corrosion Cracking Resistance
	Small Arm Ammunition:Primer Caps, Bullet Jackets	Forming Characteristics	Formability
	Small Arm Ammunition:Primer Caps, Bullet Jackets	Mechanical Properties	Moderate Strength
Other	Coins	Appearance	Appearance
	Coins	Forming Characteristics	Coinability
	Coins	Plating Characteristics	Plateable
	Medals	Appearance	Appearance
	Medals	Corrosion Resistance	Corrosion Resistance
	Medals	Forming Characteristics	Formability
	Medals	Mechanical Properties	Moderate Strength
	Medals	Plating Characteristics	Plateable
	Tokens	Corrosion Resistance	Corrosion Resistance
	Tokens	Forming Characteristics	Coinability
	Tokens	Forming Characteristics	Formability
	Tokens	Mechanical Properties	Moderate Strength

Applicable Specifications

Form	Specific Sub-Form	Application	System	Standard	Description
Bar			ASTM	B36/B36M	BRASS PLATE, SHEET, STRIP AND ROLLED BAR
			SAE	J463	WROUGHT COPPER AND COPPER ALLOYS
			SAE	J461	WROUGHT AND CAST COPPER ALLOYS
Plate			ASTM	B36/B36M	BRASS PLATE, SHEET, STRIP AND ROLLED BAR
Rod, Bar & Shapes			ASTM	B927/B927M	BRASS ROD, BAR, AND SHAPES
Sheet			ASTM	B36/B36M	BRASS PLATE, SHEET, STRIP AND ROLLED BAR
			SAE	J461	WROUGHT AND CAST COPPER ALLOYS
			SAE	J463	WROUGHT COPPER AND COPPER ALLOYS
Strip			SAE	J463	WROUGHT COPPER AND COPPER ALLOYS
			ASTM	B36/B36M	BRASS PLATE, SHEET, STRIP AND ROLLED BAR
			SAE	J461	WROUGHT AND CAST COPPER ALLOYS
Tube			ASTM	B587	WELDED BRASS TUBE
Wire			ASTM	B134/B134M	BRASS WIRE

If you need product information or price, please fill in your contact information in the form, we will usually contact you within 12 hours. You could also email me info@lyapm.com to get prompt reply.

1. Stock view



2. Processing and Technology for heating processing

Cutting processing      Quenching              Tempering                  Annealing



3. Quality testing

1.      Inspection Institution

Shanghai Fuda Testing Technology Group Co., LTD. Nanjing Branch

Focus on analysis, testing, testing, r & D four service areas. Analysis fields include component analysis, formula analysis, failure analysis, structure analysis, methodology development and validation, raw material quality control/evaluation, consistency evaluation, feature analysis and other directions; The testing field involves physical and chemical properties testing, toxic and harmful substances testing, flame retardant performance testing, reliability testing and other directions; The testing field involves energy spectrum, electron microscope, spectrum, chromatography, mass spectrometry and other directions; The r&d field involves formula development, formula upgrading, formula customisation, cooperative research and development and other directions.

Beijing Zhongke Chemical Technology Research Institute

It is a chemical technology research institution based on scientific research and testing. They adhere to paying equal attention to basic research and applied research, and combining applied research and technology transformation, developing into a comprehensive research institute characterised by "task-oriented disciplines". Approved by the relevant national departments, the company has become a third-party analysis and testing technology service unit, and has obtained CMA qualification certification. It has carried out research and development and design, analysis and testing, test and verification, generic processing, information and intellectual property services, providing public services for innovation of technology-based enterprises. Supported by the government innovation Fund, the institute has been awarded as a national high-tech enterprise.



2.Inspection Machining



   Metal composition testing machine                      Computerised Materials Torsion Testing Machine                Metal bar composite rod bending tensile strength testing machine

       3. Material test certificate

     4. Packaging

    In the steel export activities, we also need to pack the steel to prevent the steel from being scattered in the transportation process. In the hoisting process, it is necessary to lift the steel. So steel is very necessary in the export process. Below is the picture of packaging：

According to the requirements of the state of steel materials, the use of binding, bare, frame, pallet.

Packing standard: according to the following national standard requirements (the parts beyond the requirements will be specified separately)

GB／T191 packaging-pictorial marking for handling of goods

GB／T4857 (all parts) basic test for transport packages

GB／T4879 rustproof packaging

GB／T5048 damp-proof packing

GB／T7350water-proof packing

GB／T8166 Package cushioning design

GB/T4892-1996  Hard straight square transport packaging size series

GB/T13201-91 Cylinder transport package size series

 GB/T16471-1996Design and make the size limit of transport package

5. Logistic



1. Company profile

Luoyue Precision Metal established in 2018, is a leading Stockists and global distributor for Metal Raw Materials like Steel/Aluminum/ Stainless steel/Copper/ Nickel Rods, Bars, Plates, Sheets,Pipes, fittings, fasteners, Inconel alloys, Wire and Wire-Mesh to customers from aerospace, automotive, electronics, precision manufacturing, ordnance, marine, shipbuilding, oil & gas, power plant and construction.

The company has a high-precision, high-efficiency modern processing site, CNC machine tools and complete testing and inspection technology, and introduces international advanced technologies.

           2. Certificates. (Business certificate/ISO9001/Trading certificate/SGS/FormE)

                  .

          3. Our customers

                 Customer visits

           4. Past Inquiry

                  .

   1.Customer Rating



FAQ
1. Q: Are you a manufacturer?
 A:No, we are not manufacturers. We have our own warehouse and our own company. I believe we will be the most suitable supplier for you.
2. Could we visit your factory?
 A: Sure, we welcome you to visit the factory , check our production lines and know more about our strength and quality.
3. Q: Do you have quality control system?
 A: Yes, we have ISO, BV, SGS certifications and our own quality control laboratory.
4. Q: Can you arrange the shipment for us?
 A: Yes, we have designated sea freight and railway freight forwarders with decades of experiences and we get the best  price with earliest vessel and professional service.
5. Q: How long is the delivery time?
 A: Generally it is 7 days if we have the exact goods in our stock. If not, it will take around 15-20 days to get goods ready for delivery.
6. Q: Can I get some samples?
 A: We are glad to provide free samples to you, but we do not offer the freight.
7. Q: What is your after-sale service?
 A: We provide after-sale service and offer 100% guarantee on our products.
8. Q: What is your MOQ?
 A: 2 Tons

Contact us
