Chemical Composition

	Elements
	Cu(1)	Pb	Zn	Fe
(1) Cu + Sum of Named Elements 99.8% min.
Min (%)	84.0
Max (%)	86.0	0.05	Rem	0.05

Mechanical Properties *

Form	Temper	Temper Code	Tensile Strength (ksi)	YS-0.5% Ext (ksi)	Elongation (%)	Rockwell B scale	Rockwell F scale	Rockwell 30T scale	Shear Strength (ksi)	Torsion Modulus (ksi)	Fatigue Strength** (ksi)	Section Size (in)	Cold Work (%)
* Measured at room temperature, 68°F (20°C).** Fatigue Strength: 100 x 106 cycles, unless indicated as [N] x 106.
Flat Products	1/2 Hard	H02	57 Typ		12 Typ	65 Typ		60 Typ	37 Typ			0.04
	1/4 Hard	H01	49 Typ			45 Typ		48 Typ
	1/8 Hard	H00	43 Typ	16 Typ	44 Typ		66 Typ	28 Typ	32 Typ			0.04
	As Hot Rolled	M20	42 Typ
	Extra Hard	H06	78 Typ	61 Typ	4 Typ	83 Typ		72 Typ	44 Typ			0.04
	Hard	H04	70 Typ	57 Typ	5 Typ	77 Typ		68 Typ	42 Typ	6.4 Typ	20 Typ	0.04
	Nominal Grain Size 0.015 mm	OS015	45 Typ	18 Typ	42 Typ		71 Typ	38 Typ	33 Typ			0.04
	Nominal Grain Size 0.025 mm	OS025	43 Typ	16 Typ	44 Typ		66 Typ	28 Typ	32 Typ			0.04
	Nominal Grain Size 0.035 mm	OS035	41 Typ	14 Typ	46 Typ		63 Typ	22 Typ	31 Typ			0.04
	Nominal Grain Size 0.050 mm	OS050	40 Typ	12 Typ	47 Typ		59 Typ	14 Typ	31 Typ			0.04
	Nominal Grain Size 0.070 mm	OS070	39 Typ	10 Typ	48 Typ		56 Typ	10 Typ	31 Typ			0.04
	Spring	H08	84 Typ	63 Typ	3 Typ	86 Typ		74 Typ	46 Typ			0.04
Pipe	Nominal Grain Size 0.015 mm	OS015	44 Typ		45 Typ		71 Typ
Tube	Hard Drawn	H80	70 Typ		8 Typ	77 Typ		68 Typ				0.065	35
	Light Drawn, Light Cold Rolled	H55	50 Typ	40 Typ	30 Typ	55 Typ		54 Typ				0.065	15
	Nominal Grain Size 0.015 mm	OS015	44 Typ	18 Typ	45 Typ		71 Typ	38 Typ				0.065
	Nominal Grain Size 0.050 mm	OS050	40 Typ	12 Typ	55 Typ		60 Typ	15 Typ				0.065
Wire	1/2 Hard	H02	72 Typ		8 Typ				43 Typ			0.08
	1/4 Hard	H01	59 Typ		11 Typ				38 Typ			0.08
	1/8 Hard	H00	50 Typ		25 Typ				35 Typ		20 Typ	0.08
	Hard	H04	88 Typ		6 Typ				48 Typ			0.08
	Nominal Grain Size 0.015 mm	OS015	45 Typ						33 Typ			0.08
	Nominal Grain Size 0.025 mm	OS025	43 Typ						32 Typ			0.08
	Nominal Grain Size 0.035 mm	OS035	41 Typ		48 Typ				31 Typ			0.08
	Spring	H08	105 Typ						54 Typ			0.08

Physical Properties

Melting Point - Liquidus°F	1880
Melting Point - Solidus°F	1810
Densitylb/cu in. at 68°F	0.316
Specific Gravity	8.75
Electrical Conductivity% IACS at 68°F	37
Thermal ConductivityBtu/ sq ft/ ft hr/ °F at 68°F	92
Coefficient of Thermal Expansion 68-57210 to -6 power per °F (68 – 572°F)	10.4
Specific Heat CapacityBtu/ lb /°F at 68°F	0.09
Modulus of Elasticity in Tensionksi	17000
Modulus of Rigidityksi	6400

Fabrication Properties

Technique	Suitability
Soldering	Excellent
Brazing	Excellent
Oxyacetylene Welding	Good
Gas Shielded Arc Welding	Good
Coated Metal Arc Welding	Not Recommended
Spot Weld	Fair
Seam Weld	Not Recommended
Butt Weld	Good
Capacity for Being Cold Worked	Excellent
Capacity for Being Hot Formed	Good
Machinability Rating	30
